| Minifinger joint cutterhead with replaceable Marathon knives TH-283-284 |
|
|
| |
| Thông số kỹ thuật: |
ZL 10/10 and 10/11 mm
WM 620-2-06
D
mm |
SB
mm |
BO
mm |
ND
mm |
Z |
TG |
ZA
PCS |
nmax
min-1 |
ID
ZL 10/10 |
|
ID
ZL 10/11 |
|
| 160 |
31.4 |
50 |
30.4 |
2/2 |
3.8 |
8 |
8 000 |
135900 |
|
135902 |
|
| 250 |
31.4 |
50 |
30.4 |
3/3 |
3.8 |
8 |
4 500 |
135901 |
|
135903 |
|
ZL 15/15 and 15/16.5 mm
WM 620-2-06
D
mm |
SB
mm |
BO
mm |
ND
mm |
Z |
TG |
ZA
PCS |
nmax
min-1 |
ID
ZL 15/15 |
|
ID
ZL 15/16,5 |
|
| 170 |
31.4 |
50 |
30.4 |
2/2 |
3.8 |
8 |
8 000 |
135904 |
|
135906 |
|
| 260 |
31.4 |
50 |
30.4 |
3/3 |
3.8 |
8 |
4 500 |
135905 |
|
135907 |
|
ZL 20/20 and 20/22 mm
WM 620-2-06
D
mm |
SB
mm |
BO
mm |
ND
mm |
Z |
TG |
ZA
PCS |
nmax
min-1 |
ID
ZL 20/20 |
|
ID
ZL 20/22 |
|
| 180 |
39.2 |
50 |
37.2 |
2/2 |
6.2 |
6 |
8 000 |
135908 |
|
135910 |
|
| 260 |
39.2 |
50 |
37.2 |
3/3 |
6.2 |
6 |
4 500 |
135909 |
|
135911 |
|
Minifinger knives with larger tip gap for supporting components particularly suitable for finger joint machines with horizontal working spindle and without cut off saws and for PU adhesives.
Spare knives
| Cut off saws |
Tip gap |
Profile knife |
ZL
mm |
TG |
ZA
PCS |
ID
2 |
|
ID
3 |
|
| without |
standard |
right |
10/10 |
3.8 |
4 |
611452 |
|
611552 |
|
| without |
standard |
left |
10/10 |
3.8 |
4 |
611453 |
|
611553 |
|
| without |
standard |
right |
15/15 |
3.8 |
4 |
611454 |
|
611554 |
|
| without |
standard |
left |
15/15 |
3.8 |
4 |
611455 |
|
611555 |
|
| without |
standard |
right |
20/20 |
6.2 |
3 |
611456 |
|
611556 |
|
| without |
standard |
left |
20/20 |
6.2 |
3 |
611457 |
|
611557 |
|
| with |
standard |
right |
10/11 |
3.8 |
4 |
611450 |
|
611550 |
|
| with |
standard |
left |
10/11 |
3.8 |
4 |
611458 |
|
611558 |
|
| with |
standard |
right |
15/16.5 |
3.8 |
4 |
611459 |
|
611559 |
|
| with |
standard |
left |
15/16.5 |
3.8 |
4 |
611460 |
|
611560 |
|
| with |
standard |
right |
20/22 |
6.2 |
3 |
611461 |
|
611561 |
|
| with |
standard |
left |
20/22 |
6.2 |
3 |
611451 |
|
611551 |
|
| without |
large |
right |
10/10 |
3.8 |
4 |
611474 |
|
611574 |
|
| without |
large |
left |
10/10 |
3.8 |
4 |
611475 |
|
611575 |
|
| without |
large |
right |
15/15 |
3.8 |
4 |
611476 |
|
611576 |
|
| without |
large |
left |
15/15 |
3.8 |
4 |
611477 |
|
611577 |
|
| without |
large |
right |
20/20 |
6.2 |
3 |
611478 |
|
611578 |
|
| without |
large |
left |
20/20 |
6.2 |
3 |
611479 |
|
611579 |
|
Cutterhead - block knife with pitch 3.8mm
Finger length
10 and 10/11mm
15 and 15/15.6mm |
|
| SB |
31.1mm |
| Hub |
30.4mm |
| ZA |
Tooth row 8 |
| Wood thickness |
Quantity of cutterheads |
| 28 |
1 |
| 58 |
2 |
| 89 |
3 |
| 119 |
4 |
| 150 |
5 |
| 180 |
6 |
| 210 |
7 |
| 241 |
8 |
| 271 |
9 |
| 302 |
10 |
| 332 |
11 |
| 362 |
12 |
Cutterhead - block knife with pitch 6.2mm
Finger length
22/20mm
22/22mm |
|
| SB |
39.2mm |
| Hub |
37.2mm |
| ZA |
Tooth row 6 |
| Wood thickness |
Quantity of cutterheads |
| 34 |
1 |
| 71 |
2 |
| 108 |
3 |
| 145 |
4 |
| 183 |
5 |
| 220 |
6 |
| 257 |
7 |
| 294 |
8 |
| 331 |
9 |
| 368 |
10 |
Table to determine the quantity of cutterheads for given wood thickness
|
|
|
